Fairchild Semiconductor FDC2612 200V N-Channel PowerTrench MOSFET Datasheet

The document is the datasheet of FDC2612.

Brand: Fairchild
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 5
File format: PDF
File size: 202 KB
Published: 11 July, 2012
Updated: 30 September, 2023
MD5 checksum: 2209653EEEE085B089C1A2A3B81FBB5B
PDF: Fairchild Semiconductor FDC2612 200V N-Channel PowerTrench MOSFET Datasheet PDF

About this manual

The FDC2612 is a 200V N-Channel MOSFET designed specifically to improve the efficiency of DC/DC converters using synchronous or conventional switching PWM controllers. It features low gate charge, low on-resistance, and fast switching speed.

What's inside

General Description
Applications
Features
Absolute Maximum Ratings
Thermal Characteristics
Electrical Characteristics
Typical Characteristics
Package Marking and Ordering Information
Trademarks
Disclaimer

Specifications

Drain-Source Voltage	200 V
Operating Junction Temperature	-55 to +150 °C
Gate Charge (Typical)	8 nC
On-Resistance (Typical)	725 mΩ

Frequently asked questions

What is the primary application of the FDC2612?

It is designed specifically to improve the overall efficiency of DC/DC converters using either synchronous or conventional switching PWM controllers.

What is the maximum continuous drain current?

The maximum continuous drain current is 1.1 A.

What is the typical gate charge?

The typical gate charge is 8 nC.
