Motorola MC10E256/MC100E256 2Bit 4:1 Mux-Latch Datasheet

This data sheet provides data for the MC10E/100E256, including pin definitions, function table and logic diagram.


Motorola MC10E256/MC100E256 2Bit 4:1 Mux-Latch Datasheet - cover page
Brand
Motorola
Category
Other Electronics
Document type
Datasheet
Language
English
Pages
6
File format
PDF
File size
69 KB
Published
10 July, 2012
Updated
01 October, 2023
MD5 checksum
AB6C7F043EAF66149C11DB536D86E36F

About this manual

This datasheet describes the MC10E256 and MC100E256, which contain three 4:1 multiplexers followed by transparent latches with differential outputs. The devices feature separate select controls for the leading 2:1 mux pairs and include a Master Reset (MR) to set outputs LOW.

Key specifications include a maximum delay from data to output of 950ps and a maximum delay from Latch Enable to output of 850ps. The MC100E variant supports an extended VEE range of -4.2V to -5.46V. The document provides logic diagrams, DC and AC characteristics, and outline dimensions for the 28-lead PLCC package.

What's inside

  • 2Bit 4:1 Mux-Latch
  • Logic Diagram
  • DC Characteristics
  • AC Characteristics
  • Outline Dimensions
  • Pinout
  • Function Table
  • Package Information

Specifications

Max D to Output Delay950ps
Max LEN to Output Delay850ps
MC100E VEE Range-4.2V to -5.46V
Input Pulldown Resistors75kQ
Package Type28-Lead PLCC

Frequently asked questions

What is the function of the Master Reset (MR)?

The Master Reset overrides all other controls to set the Q outputs LOW.

When is the latch transparent?

The latch is transparent when the Latch Enable (LEN) is LOW.
