BG40-47/DHE09XA4C/C3 is a 2.2 kW power AC three-phase electric motor and gear box combination product produced by BorgWarner Germany. The product has an IP66 protection rating, 50Hz working frequency, 4.75A rated current, 84.5% rated efficiency, and meets EN60034-2-1 standard.
This document provides technical specifications for a Bauer Gear Motor with model number BG40-47/DHEO9XA4C/C3. The unit is a two-stage spur gear drive coupled with a three-phase cage induction motor.
Key performance figures listed include an output power of 5 kW, a torque of 71 Nm, and a rated speed of 295 r/min. The motor operates at 400V/50Hz with an efficiency class of IE2 (84.5%). This manual is written in German.
| Output Power | 5 kW |
|---|---|
| Torque | 71 Nm |
| Rated Speed | 295 r/min |
| Gear Ratio | 14.94 |
| Voltage | 400 V |
| Frequency | 50 Hz |
| Efficiency Class | IE2 - 84,5 % |
| Protection Rating | IP 66 |
The motor has a rated power of 5.2 kW.
The rated speed is 1440 r/min.
The total reduction ratio is 14.94.
