The manual provides safety guidelines, installation steps, wiring, programming, and troubleshooting for the Danfoss MG.11.AE.41 HVAC inverter.
This document explains the safety precautions, mechanical and electrical installation requirements, and the procedures for commissioning the VLT® HVAC inverter. It includes detailed wiring diagrams, control terminal functions, and recommended cooling gaps.
The guide also covers the user interface, programming examples, application settings, status monitoring, alarm handling, fault diagnosis, and technical specifications such as input voltage range, power ratings, efficiency, and weight. This manual is written in Chinese.
| Input voltage | 200‑240 VAC |
|---|---|
| Enclosure weight (IP20) | 4.9 kg |
| Continuous output current (200‑240 V) | 6.6 A |
Wait the minimum time shown in Table 1.1, e.g., 5 minutes for 41 V or 1.1 minutes for 200‑240 V.
A minimum air gap of 100‑225 mm (4‑10 inches) should be left at the top and bottom of the enclosure.
