2PD601A is a NPN general purpose transistor produced by Philips Semiconductors. This transistor has the characteristics of low current (maximum 100mA) and low voltage (maximum 50V). It is mainly used for general purpose switching and amplification.
This document is a datasheet for the Philips 2PD601A, which is an NPN general purpose transistor designed for low current (max. 100 mA) and low voltage (max. 50 V) applications. It is suitable for general purpose switching and amplification tasks.
| Collector current (DC) | 100 mA |
|---|---|
| Peak collector current | 200 mA |
| Collector-emitter voltage | 50 V |
| Total power dissipation | 250 mW |
| Package type | SC-59 plastic package |
The maximum DC collector current is 100 mA.
The maximum total power dissipation is 250 mW.
The thermal resistance from junction to ambient is 500 K/W.
