This user’s guide serves as a reference book for the THS1206/THS12082/THS10064/THS10082 evaluation module. It describes the operation and usage of the 12-bit THS1206/THS12082 and 10-bit THS10064/THS10082 analog-to-digital converter (ADC) evaluation modules.
This user's guide serves as a reference book for the THS1206/THS12082/THS10064/THS10082 evaluation module (EVM). It describes the operation and usage of these 12-bit and 10-bit analog-to-digital converter (ADC) evaluation modules. The document covers EVM description, common-connector interface details, physical descriptions including bill of materials, and schematics.
The evaluation module requires a supply voltage ranging from 6 V to 10 V.
The analog input voltage range is from -1 V to 1 V.
