THS10082 is a low-power 10-bit 8MSPS analog-to-digital converter (ADC) suitable for radar, imaging, high-speed acquisition, and communications applications. Its features are speed, resolution, bandwidth, and single-supply operation. The device uses a multi-stage pipelined architecture with output error correction logic to prevent code loss over the entire operating temperature range. Internal control registers allow for programming the ADC into the desired mode. The THS10082 consists of two analog inputs, which can be individually selected and configured for single-ended or differential inputs. An integrated 16-word deep FIFO allows data to be stored to relieve the processor burden.
The THS10082 is a CMOS, low-power analog-to-digital converter (ADC) designed for radar, communications, control applications, and high-speed DSP front-ends. It features simultaneous sampling of two single-ended signals or one differential signal with an integrated 16-word FIFO to reduce processor load.
The device offers a resolution of 10 bits with a Signal-to-Noise and Distortion Ratio (SINAD) of 59 dB at fI = 2 MHz. It supports both single conversion mode using an internal clock oscillator and continuous conversion mode driven by an external clock signal.
| Resolution | 10 Bits |
|---|---|
| Differential Nonlinearity Error | +1 LSB |
| Integral Nonlinearity Error | +1 LSB |
The THS10082C is characterized for operation from 0°C to 70°C, and the THS10082I is characterized for operation from -40°C to 85°C.
Yes, it supports simultaneous sampling of two single-ended signals or one differential signal.
