The THS1060 is a high performance communication analog-to-digital converter (ADC) from Texas Instruments. It uses a 10-bit CMOS process and has a maximum sampling rate of 60 MS/s. The maximum resolution is 10 bits and the product has no missing codes. It also has an on-chip sample and hold function. The THS1060 is suitable for a variety of applications, including wireless local loop, wireless internet access, cable modem receivers, medical ultrasound, and magnetic resonance imaging.
The THS1060 is a high-speed, low-noise 10-bit CMOS pipelined analog-to-digital converter designed for wireless local loop, cable modem receivers, and medical ultrasound applications. It features a differential sample and hold to minimize even-order harmonics and allows operation with either internal or external references.
| Resolution | 10-bit |
|---|---|
| Maximum Sample Rate | 60 MSPS |
| Spurious Free Dynamic Range | 73 dB |
| Analog Supply Voltage | 5 V |
| Bandwidth | 82 MHz |
| Differential Input Resistance | 900 Ω |
| Effective Number of Bits (ENOB) | 9.5 bits |
| Signal to Noise Ratio (SNR) | 60 dBFS |
Yes, it can operate with either internal or external references.
The THS1060I operates from -40°C to 85°C.
