VFT80-28 is a N-channel enhancement mode VHF power MOSFET, with a rated voltage of 60 V and a rated current of 10 A. Features 10:1 load VSWR capability and Omnigold™ metallization system.
The ASI VFT80-28 is an N-channel enhancement mode power MOSFET designed specifically for General Purpose Class B Power Amplifier Applications up to 175 MHz. It features a typical gain (Pg) of 10 dB at 175 MHz and includes a 10:1 Load VSWR capability.
| Frequency Range | up to 175 MHz |
|---|---|
| Channel Type | N-Channel Enhancement Mode |
| Typical Gain at 175 MHz | 10 dB |
| Load VSWR Capability | 10:1 |
| Operating Temperature Range (Tj) | -65 °C to +200 °C |
The VFT80-28 is designed for applications up to 175 MHz.
The device has a typical gain of 10 dB at 175 MHz.
