UML1 is a NPN silicon RF power transistor with the following features: Omnigold™ Metalization System, maximum current 2.0A, maximum voltage 45V, maximum power 31.8W, package type 4L STUD
The ASI UML1 is an NPN silicon RF power transistor designed for use with the Omnigold™ Metalization System. It is packaged in a 4L stud style package with specific mechanical dimensions provided in the document.
The document details the maximum ratings, including collector current of 2.0A and a maximum power dissipation of 31.8W at 25°C. It also lists key electrical characteristics such as collector-emitter breakdown voltage and transition frequency.
| Package Style | 4L Stud |
|---|---|
| Operating Temperature Range | -65 °C to +200 °C |
| Storage Temperature Range | -65 °C to +150 °C |
The order code for the ASI UML1 is ASI10688.
The ASI UML1 is designed for the Omnigold™ Metalization System.
