molex 88741 handbook

MicroCross™ DVI Digital Visual Interface Shielded I/O Cable Assembly 88741 DVI-Digital to P&D-Digital is a product with LFH™(Low Force Helix) rugged contacts that offer increased life cycle, mechanical and electrical reliability. This product supports up to 1.65 Gbs bandwidth and is fully shielded against RFI/EMI. Additionally, this product comes with ground detents and solder tails for cable termination and a positive retention jackscrew.

Brand: Molex
File format: PDF
Published: 07 June, 2012
Updated: 30 September, 2023
MD5 checksum: 5FDBD6D2A25C4E29EBF83D040966382C
PDF: molex 88741 handbook PDF

Download PDF
