The SPC20058 data sheet provides detailed specifications for a 6‑ft modem cable assembly featuring DB25 male and DB9 female connectors. It includes wiring color codes, connector materials, and dimensional tolerances.
Key sections cover pin‑out tables, molded connector end requirements, wire gauge and insulation details, as well as hardware dimensions such as thumbscrew size and plating finishes.
| Wire gauge | 28AWG (7/0.12) |
|---|---|
| Wire outer diameter | 0.784 mm |
| Connector type DB25 | Male, Nickel plating |
| Connector type DB9 | Female, Nickel plating |
| Thumbscrew size | 4 × 47 mm, Nickel plating |
