This datasheet describes the mechanical and electrical specifications of the SPC TA-433 connector and cable assembly. It includes typical connector length, insulation and jacket dimensions, pin configurations, and material finishes.
The document also lists part numbers for individual components such as ferrite cores, thumbscrews, and high‑density 15‑pin male and female connectors, useful for designers and manufacturers requiring precise part data.
| Length | 1.80 mm (45.5 mil) |
|---|---|
| Cable insulation outer diameter | 1.6+0.5 mm |
| Jacket outer diameter | 2.60+0.10 mm |
| Pin count (male connector) | 15 pins |
| Ferrite core dimensions | 28.5 x 17.5 x 10 mm |
The typical connector length is 1.80 mm (45.5 mil).
The cable insulation uses FO‑PE with an outer diameter of about 1.6+0.5 mm.
It has 15 pins.
