The SPC4800 is a USB Type‑A (male, 4‑pin) to USB Type‑B (female, 4‑pin) cable assembly designed for full‑speed USB applications. The document provides the mechanical, electrical, and environmental specifications required for integration and compliance.
Key features include a thermoplastic housing with glass‑fiber fill, phosphor‑bronze contacts with gold plating, and a steel shell with tin‑lead plating. Electrical ratings, insertion/withdrawal forces, and durability test limits are also listed.
| Voltage rating | 30 V AC |
|---|---|
| Maximum current per contact | 1 A |
| Insertion force | 4 kg max |
| Withdrawal force | 1–4 kg |
| Random vibration tolerance | No discontinuity of 1.5 s or longer |
| Physical shock tolerance | No discontinuity of 4 s or longer |
| Thermal shock cycles | 10 cycles –55 °C to +85 °C |
| Connector types | USB Type‑A male 4‑pin, USB Type‑B female 4‑pin |
| Shell material | Steel, tin‑lead plating over copper under‑plating |
The cable is rated for 30 V AC.
Each contact can carry up to 1 A.
It uses a USB Type‑A male 4‑pin connector and a USB Type‑B female 4‑pin connector.
Insertion force is limited to 4 kg max, and withdrawal force ranges from 1 to 4 kg.
