This document provides the complete technical specifications for Hitachi's SP14Q006 LCD module, including mechanical dimensions, electrical ratings, and optical performance. It is intended for designers and engineers who need detailed data for integration and verification.
Key information includes absolute maximum ratings, power supply requirements, LED backlight characteristics, contrast ratio, response times, and environmental limits. The data is presented in tables and diagrams for quick reference.
| Outer Dimensions | 167.0 mm (W) × 109.0 mm (H) |
|---|---|
| Input Voltage Range | -0.3 V to +0.3 V |
| Operating Ambient Temperature | -20 °C to 70 °C |
| LED Backlight Supply Voltage | 5 V typ, 5.2 V max |
| LED Backlight Current | 160 mA max |
| Contrast Ratio | 25 : 1 (typ) |
| Response Time (Rise) | 336 ms |
| Resolution | 320 × 240 dots |
The module can operate from –20 °C up to 70 °C.
The LED backlight is powered at a typical 5 V with a maximum of 5.2 V.
The LCD module has a resolution of 320 × 240 dots.
