The S1D2503X01-D0B0 is a very high frequency video amplifier system with I2C bus control used in monitors with high resolution up to 1600 × 1200. It contains 3 matched R/G/B video amplifiers with OSD interface and provides flexible interfacing to I2C bus controlled adjustment systems.
The S1D2503X01-D0B0 is a 200 MHz I²C‑bus controlled RGB video amplifier designed for high‑resolution monitors up to 1600 × 1200. It integrates three matched video channels with OSD functionality and provides digital control of contrast, brightness, sub‑contrast, cut‑off, and beam limitation.
Key features include a 32‑DIP‑600A package, operating temperature range of –25 °C to +80 °C, TTL OSD inputs, built‑in clamp and half‑tone functions, and a 7 Vp‑p output swing. The datasheet lists detailed pin configurations, descriptions, and typical application circuits.
| Package | 32-DIP-600A |
|---|---|
| Operating Temperature | -25°C—+80°C |
| Bandwidth | 200 MHz (‑3 dB) |
| Contrast control range | 38 dB |
| SUB contrast control range | 11 dB |
| OSD contrast control range | 38 dB |
| Output swing | 7 Vp‑p |
| Maximum video input level (Red) | 0.7 Vpp |
It uses an I²C bus for digital control of all functions.
The device contains three matched R/G/B video channels.
ABL stands for Automatic Beam Limitation, providing beam current limitation.
Pins 1, 2, and 3 (ROSD, GOSD, BOSD) are the red, green, and blue OSD inputs.
