S1D2504A01 is an I2C bus controlled RGB video amplifier used in monitors. It contains 3 matched RGB video amplifiers and provides flexible interfacing to the I2C bus controlled adjustment systems.
The S1D2504A01 is a high‑frequency video amplifier system with I2C‑bus control, intended for monitor applications. It integrates three matched R/G/B video amplifiers and offers flexible interfacing for contrast, brightness, and cut‑off adjustments.
The document lists the pin configuration, electrical ratings, and functional blocks, including automatic beam limitation, clamp gate control, and built‑in video output brightness clamp. Key electrical parameters such as operating temperature, power dissipation, and I2C bus characteristics are also provided.
| Video channels | 3 (R/G/B) |
|---|---|
| Bandwidth | 85 MHz @ -3 dB |
| Contrast control range | -38 dB |
| SUB contrast control range | -11 dB |
| Output swing | 7 Vpp |
| Maximum power dissipation | 1.5 W |
It uses an I2C bus for control.
Three channels – red, green, and blue – are supported.
The contrast control can be set from –38 dB.
