The S1D2518X01 is a high frequency video amplifier system with I2C bus control used in monitors. It contains 3 matched R/G/B video amplifiers with OSD interface and provides flexible interfacing to I2C bus controlled adjustment systems.
The $1D2518X01 is a high‑frequency video amplifier system with I²C bus control, designed for monitor applications. It integrates three matched R/G/B channels, each with independent contrast, brightness, and cut‑off controls, as well as OSD and half‑tone functions.
The datasheet provides a block diagram, pin configuration and description, typical application circuit, and package dimensions. Key features include a 150 MHz video bandwidth, 7 Vp‑p output swing, and built‑in automatic beam limitation and clamp gate circuits.
| Package | 30‑SDIP‑400 |
|---|---|
| Operating Temperature | -25 to +75 °C |
| Video Bandwidth | 150 MHz |
| TTL OSD Input Bandwidth | 80 MHz |
| Contrast Control Range | 38 dB |
| Sub‑Contrast Control Range | 11 dB |
| OSD Contrast Control Range | 38 dB |
| Output Swing | 7 Vp‑p |
| Number of Channels | 3 |
It is controlled via an I²C bus.
The device provides three matched R/G/B video channels.
The device operates from –25 °C to +75 °C.
It is supplied in a 30‑SDIP‑400 package.
