The S1D2512X01 is a deflection processor for multi-mode or multi-frequency computer display monitors. It controls all the functions related to horizontal and vertical deflection and has an internal sync processor and powerful geometry correction capabilities, making it suitable for high-performance monitors. It is particularly well suited for high-end 17-inch and 19-inch monitors.
The S1D2512X01 is a monolithic integrated circuit in a 32‑pin shrink‑DIP package that controls horizontal and vertical deflection for multisync computer display monitors. It integrates a sync processor, geometry correction block, and B+ regulator to enable high‑performance display operation with low jitter.
Key features include self‑adaptive horizontal control, dual PLL, vertical ramp generator, geometry tracking, X‑RAY protection, and programmable B+ regulation. The datasheet provides full pin descriptions, absolute maximum ratings, thermal characteristics, and recommended application circuits.
| Horizontal frequency range | 15 to 150 kHz |
|---|---|
| Vertical frequency range | 35 to 200 Hz |
| Supply voltage (Pin 29) max | 13.5 V |
| Operating temperature range | 0 °C to +70 °C |
| Junction temperature max | +150 °C |
| Package type | 32‑pin shrink‑DIP (32‑SDIP‑400) |
It is supplied in a 32‑pin shrink dual‑in‑line plastic package (32‑SDIP‑400).
The device supports up to 150 kHz horizontal frequency.
It operates from 0 °C up to +70 °C.
Pin 29 may be exposed to a maximum of 13.5 V.
