This product is a PC 4/ 2-STF-7,62 plug component produced by PHOENIX CONTACT. Its rated current is 20A, rated voltage is 400V, interface type is screw connection and its color is green.
The PC 4/2-STF-7,62 is a 2‑position screw‑connection terminal block with a 7.62 mm pitch, designed for 20 A nominal current and up to 400 V nominal voltage. It is supplied in a green‑colored housing and complies with RoHS/WEEE regulations.
The document lists detailed technical data such as tightening torque, surge voltage ratings, insulating material, and conductor cross‑section ranges, as well as accessories, certification approvals (CSA, CUL, UL, etc.), and derating curves for temperature.
| Nominal current | 20 A |
|---|---|
| Nominal voltage | 400 V |
| Pitch | 7.62 mm |
| Number of positions | 2 |
| Connection type | Screw connection |
| Color | green |
| Weight per piece | 0.01191 kg |
The terminal block is rated for a nominal current of 20 A.
The pitch of the terminal block is 7.62 mm.
A tightening torque of 0.5 Nm minimum and 0.6 Nm maximum is recommended.
It is certified by CSA, CUL, DNV, GL, GOST, LR, and UL.
