FK-MCP 1,5/ 5-STF-3,81 is a plug component made by PHOENIX CONTACT. Its rated current is 8 A, rated voltage is 160 V, pitch is 3.81 mm, number is 5, connection type is spring-cage connection, and color is green.
The FK-MCP 1,5/5-STF-3,81 is a 5‑position terminal block with a 3.81 mm pitch, designed for direct mounting, DIN‑rail, or press‑in applications. It is rated for 8 A nominal current and 160 V nominal voltage, and is supplied in a green housing.
The product complies with multiple safety standards (CSA, CUL, UL, VDE‑PZI) and includes accessories such as marker cards and a screwdriver. Detailed dimensions, connection data, and certification information are provided in the sheet.
| Nominal current | 8 A |
|---|---|
| Pitch | 3.81 mm |
| Number of positions | 5 |
| Color | green |
| Certificates | CSA, CUL, UL, VDE‑PZI |
The terminal block is rated for a nominal current of 8 A.
The pitch of the terminal block is 3.81 mm.
It is certified by CSA, CUL, UL and VDE‑PZI.
The terminal block provides five positions.
