NTPS-24-1.3 is a 24V 1.3A DIN rail power supply with an input range of 100-240VAC and an output range of 24V 1.3A.
The NTPS-24-1.3 is a Class 2 power supply designed for a wide input range of 100‑240 V AC and provides a regulated DC output of 24‑28 V at up to 40 W. It includes built‑in protection features such as over‑voltage, over‑current and short‑circuit protection.
The device complies with multiple safety and EMC standards (CE, UL 60950, EN 61000‑6‑3/‑4, EN 55011/‑22) and carries an IP20 rating. Its compact dimensions (approximately 45 mm × 75 mm × 28 mm) and weight of about 230 g make it suitable for industrial and equipment applications. This manual is written in German.
| Input voltage | 100‑240 V AC |
|---|---|
| Maximum output power | 40 W |
| IP protection rating | IP20 |
| Weight | 230 g |
The supply accepts an input voltage of 100 V to 240 V AC.
It can deliver up to 40 W of output power.
The NTPS-24-1.3 has an IP20 rating.
