N-TRON 306TX Industrial Network Switch is an unmanaged six port Industrial Ethernet Switch.
The N-TRON 306TX industrial network switch provides six auto‑sensing 10/100BaseTX RJ‑45 ports in a compact DIN‑rail enclosure. It supports full/half duplex operation, auto‑negotiates speed and flow control, and offers plug‑and‑play simplicity for industrial data acquisition and control applications.
Designed for harsh environments, the switch features extended temperature and humidity ranges, redundant power inputs, LED link/activity indicators, and optional N‑View OPC monitoring for traffic analysis. It can be panel‑mounted or DIN‑rail mounted alongside other industrial equipment.
| Height | 3.1" (7.874 cm) |
|---|---|
| Width | 2.0" (5.08 cm) |
| Depth | 3.4" (8.636 cm) |
| Weight | 0.75 lbs (0.3 kg) |
| Input Voltage | 10‑30 VDC |
| Input Current | 250 mA @ 24 V |
| Inrush Current | 8.0 A / 0.6 ms @ 24 V |
| Operating Temperature | -20 °C to 70 °C |
| Storage Temperature | -40 °C to 85 °C |
| Operating Humidity | 10 % to 95 % (non‑condensing) |
| Operating Altitude | 0 to 10,000 ft |
| Shock Resistance | 200 g @ 10 ms |
| Vibration Resistance | 50 g, 5‑200 Hz, triaxial |
| Network Media (10BaseT) | Cat 3 or higher |
| Network Media (100BaseTX) | Cat 5 or higher |
| Connectors | Six RJ‑45 TX ports |
| Regulatory Approvals | FCC Part 15 Class A, UL 1604, CE |
The 306TX provides six 10/100BaseTX RJ‑45 ports.
It can be mounted on a DIN‑rail or panel‑mounted in a compact enclosure.
The device operates from –20 °C up to 70 °C.
Yes, the switch auto‑senses speed, duplex, and cable type for each port.
