The 104TX is a low-cost unmanaged four-port Industrial Ethernet Switch, featuring a compact design, full IEEE 802.3 compliance, four 10/100BaseTX RJ-45 ports, extended environmental specifications, support for full/half duplex operation, etc.
The N-TRON 104TX Industrial Network Switch is a compact, hardened metal DIN‑Rail device offering four 10/100BaseTX RJ‑45 ports with auto‑sensing, full/half duplex operation, and store‑and‑forward technology. It is designed for mission‑critical data acquisition, control, and Ethernet I/O applications, supporting up to 2,000 MAC addresses and redundant power inputs for increased reliability.
The handbook outlines product features, environmental specifications, ordering information, and regulatory approvals. It also lists detailed physical, electrical, and environmental specifications, making it a useful reference for engineers and system integrators selecting an industrial Ethernet solution.
| Height | 2.88" (7.31 cm) |
|---|---|
| Width | 1.50" (3.81 cm) |
| Depth | 3.55" (9.02 cm) |
| Weight | 0.54 lbs (0.25 kg) |
| Input Voltage | 10-30 VDC |
| Steady Input Current | 215 mA @24 V |
| Inrush Current | 7.8 A / 0.7 ms @24 V |
| Operating Temperature | -40 °C to 80 °C |
| Storage Temperature | -40 °C to 85 °C |
| Operating Humidity | 10 % to 95 % |
| Operating Altitude | 0 to 10,000 ft |
| MTBF | >2 Million Hours |
| Supported MAC Addresses | Up to 2,000 |
| Network Media (10BaseT) | Cat3 Cable |
| Network Media (100BaseTX) | Cat5 Cable |
| Connectors | Four RJ‑45 10/100BaseTX ports |
The switch operates from –40 °C to 80 °C.
It can store up to 2,000 MAC addresses.
No, it is an unmanaged switch that operates automatically.
It has redundant power inputs ranging from 10 V to 30 V DC.
