MCVR 1,5/ 4-ST-3,5 is a connector produced by Phoenix Contact. The rated current of this connector is 8A, the rated voltage is 160V, the installation hole spacing is 3.5mm, and there are 4 connection positions. The connection method is screw connection.
The MCVR 1.5/4-ST-3.5 is a screw‑connection terminal block from Phoenix Contact with a 3.5 mm pitch and four positions. It is designed for nominal currents of 8 A and rated voltages of 160 V, suitable for a 1.5 mm² conductor cross‑section.
The datasheet provides dimensions, electrical ratings, material specifications, certification information, and a list of compatible accessories and related header products. Contact details for Phoenix Contact are included at the end of the document. This manual is written in Chinese.
| Nominal current | 8 A |
|---|---|
| Rated voltage | 160 V |
| Pitch | 3.5 mm |
| Number of positions | 4 |
| Height | 12.5 mm |
| Tightening torque | 0.22 Nm |
| Insulating material group | I |
| Rated surge voltage | 2.5 kV |
| Nominal cross section | 1.5 mm² |
The nominal current is 8 A.
It supports a rated voltage of 160 V (UN).
The terminal block has four positions.
The pitch is 3.5 mm.
