This document introduces the GMSTBVA 2,5/ 3-G-7,62 product from PHOENIX CONTACT GmbH & Co. KG. The product is a 10-position connector with a nominal current of 12A, a nominal voltage of 400V, a pitch of 7.62mm, a green color, and soldering assembly. The product is WEEE/RoHS-compliant and has good insulation and voltage resistance.
The GMSTBVA 2,5/ 3-G-7,62 is a 3‑position green terminal block with a 7.62 mm pitch, rated for 12 A nominal current and 400 V nominal voltage. It is supplied as a solder‑mount component and is available in a 50‑piece pack.
The product complies with multiple certifications (CB, CSA, CUL, GOST, UL, VDE‑PZI) and is RoHS‑compliant. Accessories such as keying caps, marker cards and coding sections are listed, and detailed mechanical drawings are provided for installation.
| Nominal current | 12 A |
|---|---|
| Nominal voltage | 400 V |
| Pitch | 7.62 mm |
| Number of positions | 3 |
| Color | green |
| Weight per piece | 0.00171 kg |
| EAN | 4017918032807 |
It is rated for a nominal current of 12 A.
The terminal pitch is 7.62 mm.
The terminal block has three positions.
It is certified by CB, CSA, CUL, GOST, UL and VDE‑PZI.
