The 76650-0135 kit is a MicroClasp™ wire‑to‑board connector system offered by Molex. It uses a 2.00 mm (.079") pitch, provides a positive‑lock latch, and is available in a range of circuit counts for through‑hole and right‑angle applications. The kit is intended for use in vending/gaming machines, automotive, white goods, medical, and industrial equipment.
The datasheet lists key specifications such as a 3 A current rating, 250 V voltage rating, and support for 28‑22 AWG wire. It also includes a bill of materials with part numbers for headers, receptacles, and optional tools needed to assemble the kit.
| Circuit Size | 12, 14, 18, 20, 8 |
|---|---|
| Current Rating | 3 A |
| Mounting Style | PCB Through Hole |
| Orientation | Receptacles, Right Angle Headers |
| Pitch | 2.00 mm (.079") |
| Voltage Rating | 250 V |
| Wire Gauge (AWG) | 28‑22 |
The kit is rated for a maximum current of 3 A.
It uses a 2.00 mm (.079") pitch.
The kit is suitable for vending/gaming machines, automotive, white goods, medical, and industrial applications.
