76650-0237 is a 2.0mm pitch micro connector from Molex. It uses a friction lock connection method and provides a reliable connection interface. The kit includes pins, terminals and semi-shrouded right angle headers.
The 76650-0237 kit from Molex provides wire-to-board connectors in the CLIK-Mate™ 2.0, MicroBlade™, MicroClasp™ and Micro-Latch™ families. It includes female crimp terminals, receptacle housings and right‑angle or vertical headers for 2.00 mm pitch applications such as consumer electronics, automotive and industrial equipment.
Key specifications include a 2.00 mm pitch, current ratings up to 3 A, voltage ratings of 125 V‑250 V, and mounting options for both through‑hole and surface‑mount PCB assembly. The kit is assembled in the U.S.A and comes with a comprehensive bill of materials covering a range of circuit counts and connector styles.
| Connector Type | Wire-to-Board |
|---|---|
| Pitch | 2.00mm (.079") |
| Current Rating | 0.5‑2A, 2A, 3A |
| Mounting Style | PCB Through Hole, SMT (Surface Mount Technology) |
| Voltage Rating | 125V, 250V |
| Wire Gauge (AWG) | 26‑22, 28‑22, 30‑24 |
| Country of Origin | Kit assembled in U.S.A |
The connectors use a 2.00 mm (.079") pitch.
The kit supports current ratings of 0.5‑2 A, 2 A and up to 3 A.
Both PCB through‑hole and surface‑mount (SMT) mounting styles are offered.
Applications include data communication equipment, automotive, white goods, medical, industrial, vending/gaming machines, office automation, home entertainment, printers/faxes, digital video cameras, notebook computers, LCD/PDP televisions, PCs and monitors, and DVD players.
