The ADS8517 is a complete low-power, single 5-V supply, 16-bit sampling analog-to-digital (A/D) converter. It contains a complete, 16-bit, capacitor-based, successive approximation register (SAR) A/D converter with sample-and-hold, clock, reference, and data interface. The converter can be configured for a variety of input ranges including ±10 V, 4 V, and 5 V. For most applications, it can be configured as a low-power, compact analog front end to achieve excellent performance.
The ADS8517 is a 16‑bit analog‑to‑digital converter offering a minimum sampling rate of 200 kSPS. It supports multiple input ranges (4‑5 V, ±10 V) and provides both parallel and SPI‑compatible serial outputs. The device includes an internal 2.5 V reference and operates from a single 5 V supply.
The converter is supplied in a TSSOP‑28 package, operates over a temperature range of –40 °C to +85 °C, and dissipates as little as 47 mW (typ) at full speed. Detailed electrical characteristics, pin assignments, and mechanical dimensions are provided throughout the document.
| Resolution | 16 bits |
|---|---|
| Maximum Sampling Rate | 200 kSPS |
| Package | TSSOP‑28 (PW) |
| Storage Temperature Range | –65 °C to +150 °C |
| Maximum Junction Temperature | +165 °C |
The ADS8517 can sample at up to 200 kSPS.
The device is offered in a TSSOP‑28 (PW) package.
