Texas Instruments SN5400 / SN54LS00 / SN54S00 / SN7400 / SN74LS00 / SN74S00 Datasheet

This document is the datasheet of Intel SN5400/SN54LS00/SN7400/SN74S00/SN74LS00 devices, which introduces the functions and features of the devices

Brand: Texas Instruments
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 21
File format: PDF
File size: 769 KB
Published: 08 May, 2012
Updated: 30 September, 2023
Models: SN5400, SN54LS00, SN54S00, SN7400, SN74LS00, SN74S00
MD5 checksum: 60DE64B20914595896C3CFA62A66F387
PDF: Texas Instruments SN5400 / SN54LS00 / SN54S00 / SN7400 / SN74LS00 / SN74S00 Datasheet PDF

About this manual

The SN5400‑SN74S00 family are 2‑input positive‑NAND gates offered in a variety of plastic, ceramic and surface‑mount packages. Each device contains four independent NAND gates and operates with standard TTL/CMOS logic levels.

The document provides ordering information, package options, absolute‑maximum ratings, electrical characteristics, switching performance and packaging details for each part number. It also includes recommended operating conditions and notes on unused inputs.

What's inside

Package Options
Ordering Information
Function Table
Absolute Maximum Ratings
Electrical Characteristics
Switching Characteristics
Packaging Information
Recommended Operating Conditions

Specifications

Package thermal impedance (θJA) D package	86 °C/W

Frequently asked questions

Which package types are available for the SN7400 device?

SN7400 is offered in Plastic Small‑Outline (D, NS, PS), Shrink‑Small‑Outline (DB), Ceramic Flat (W), Ceramic Chip Carrier (FK), and standard PDIP (N) packages.

What is the recommended operating temperature range?

The devices are specified for operation from –55 °C to +125 °C.
