This product is a 300 volt 3 conductor line with UL Type CM, AWM 2464, CSA PCC FT4 certifications, high temperature resistance, easy to strip the line skin, and can be used in medical electronics, point to point sales equipment, computer peripherals, industrial process control and other scenarios.
The FOIL SHIELD UL Type CM AWM 2464 multiconductor cable from Alpha Wire provides premium‑grade PVC insulation and foil shielding for high‑technology electronic signal applications. It is designed for easy routing in tight spaces, fast stripping, and resistance to oils and temperatures up to 105 °C.
The data sheet lists detailed electrical and mechanical specifications, part numbers, flame‑test ratings, RoHS compliance, and availability information for same‑day shipment. This manual is written in Chinese.
| Operating Temperature | -20 °C to 105 °C |
|---|---|
| Voltage Rating | 300 Volt |
| Conductor | Stranded Tinned Copper |
| Insulation | Premium PVC |
| Shield | Aluminum/Polyester Foil |
| UL Type | CM, AWM Style 2464 |
| RoHS Compliance | Yes |
| Flame Test (UL) | VW‑1 |
| Flame Test (CSA) | FT4 |
The cable is rated for 300 Volt.
It can operate from –20 °C up to 105 °C.
Yes, the cable is RoHS compliant.
It passes the UL VW‑1 and CSA FT4 flame‑test standards.
