ADG3241 is a 2.5V or 3.3V single digital switch, designed on a low voltage CMOS process that provides low power dissipation yet gives high switching speed and very low on resistance
The ADG3241 is a 2‑port level‑translator bus switch available in SC70 and SOT‑66 packages. It operates from 2.5 V or 3.3 V supplies and supports level translation between 3.3 V, 2.5 V and 1.8 V signals. The device offers low propagation delay, high data‑rate capability, and low on‑resistance, making it suitable for bus switching, hot‑swap, and isolation applications.
The datasheet includes detailed electrical characteristics, absolute maximum ratings, pin descriptions, typical performance curves, and ESD handling guidance. It also lists the device’s small‑signal bandwidth, maximum data rate, and recommended usage conditions for reliable operation in mixed‑voltage systems.
| Supply voltage (Vcc) | 2.3 V to 3.6 V |
|---|---|
| Propagation delay | 225 ps |
| Small‑signal bandwidth | 770 MHz |
It can operate from a 2.5 V or 3.3 V supply, with Vcc ranging from 2.3 V to 3.6 V.
The propagation delay is 225 ps.
The device is offered in a tiny 6‑lead SC70 package and a 6‑lead SOT‑66 package.
