This document describes the features and characteristics of the ADN4690E/ADN4692E/ADN4694E/ADN4695E series high-speed M-LVDS transceivers, including a working voltage of 3.3V, support for half-duplex and full-duplex modes, support for data transfer rates of 100Mbps, compliance with the TIA/EIA-899 standard, and features such as interference resistance and ESD protection.
The ADN4694E is a multipoint low‑voltage differential signaling (M‑LVDS) transceiver that operates up to 100 Mbps (50 MHz) with a half‑duplex 8‑lead SOIC package. It offers fail‑safe bus‑idle and open‑circuit protection, enhanced ESD protection, and conforms to the TIA/EIA‑899 standard.
The document provides detailed specifications, timing parameters, absolute maximum ratings, thermal resistance, pin configurations, and typical performance curves for designers integrating the part into backplane, clock distribution, or networking applications.
