The 110-145 Watt LPQ142 Series is a single-wire power supply with active power factor correction (PFC) that meets the IEC EN61000-3-2 standard. It features 4 adjustable outputs, remote sense on main output, single wire current sharing, power fail and remote inhibit, built-in EMI filter, low output ripple, overvoltage protection, overload protection and thermal overload protection.
The LPQ142 Series is a 145‑Watt, quad‑output power supply with active power‑factor correction and IEC EN61000‑3‑2 compliance. It offers adjustable outputs on channels 1, 3, and 4, remote sense on the main output, single‑wire current sharing, and built‑in EMI filtering. Optional cover (‑C) and fan‑cover (‑CF) configurations are available.
The device operates from 85‑264 VAC or 120‑300 VDC input, delivers up to 75 % efficiency at full load, and meets multiple safety and electromagnetic compatibility standards (FCC Class B, CISPR 22, EN55022, VDE 0878 PT3, UL 60950, CE). Environmental limits include 0 °C to 50 °C operating temperature, –40 °C to 85 °C storage, 5 %–95 % non‑condensing humidity, and 0.75 G vibration tolerance.
| Input voltage | 85‑264 VAC, 120‑300 VDC |
|---|---|
| Output power | 110‑145 W |
| Number of outputs | Quad (4) |
| Efficiency at full load | 75 % typical |
| Power factor | 0.99 typical |
| MTBF | >550,000 hours at full load, 25 °C |
| Operating temperature range | 0 °C to 50 °C ambient |
| Storage temperature range | -40 °C to 85 °C |
| Humidity range | 5 % to 95 % non‑condensing |
| Vibration tolerance | 0.75 G peak, 5 Hz‑500 Hz |
The LPQ142 accepts 85‑264 VAC or 120‑300 VDC input.
It provides four (quad) independent outputs.
Typical efficiency is about 75 % at full load.
