The LPS25 series power supply features include: universal input, 3-inch x 5-inch power supply size, remote sensing, built-in EMI filter, low output ripple, adjustable output, overvoltage protection, overload protection, 110KHz switching frequency, and LPX40 enclosure kit available.
The LPS25 Series is a compact 3" × 5" power adapter featuring universal 85‑264 VAC input, 110 kHz switching, and high efficiency (70% typical). It offers adjustable output, remote sense compensation, and built‑in EMI filtering for low ripple operation.
The unit is rated for 25 W convection cooling or 40 W with 30 CFM forced air, operates from 0 °C to 50 °C, and meets multiple safety and EMC standards (FCC Class B, CISPR 22, EN55022, VDE 0878). Protection includes overload, over‑voltage, short‑circuit, and reverse‑connection safeguards, with an MTBF exceeding 550,000 hours.
| Input voltage range | 85‑264 VAC |
|---|---|
| Output voltage (LPS25) | 24 V |
| Maximum power (convection) | 25 W |
| Maximum power (forced air) | 40 W |
| Efficiency | 70 % typical at full load |
| Switching frequency | 110 kHz |
| MTBF | >550,000 hours |
| Operating temperature range | 0 °C to 50 °C |
| Remote sense compensation | 0.5 V lead drop |
| Protection features | Overvoltage, overload, short‑circuit, reverse‑connection |
The adapter accepts a universal input range of 85 VAC to 264 VAC.
It provides up to 25 W with natural convection cooling and up to 40 W when equipped with a 30 CFM forced‑air fan.
The unit includes overload, over‑voltage, short‑circuit, and reverse‑connection protection.
