JVC Monitor Calibration 2 software is a dedicated software for the GD-X1 series monitor. You can calibrate the Gamma value and White Balance for the X1 monitor, using this software with PC and photometer.
This guide explains how to install and use JVC Monitor Calibration 2, a software tool dedicated to the GD‑X1 series monitors. It covers system requirements, installation of the program and the EyeOne Display 2 driver, and how to operate the GUI for gamma and white‑balance calibration.
The manual also includes a report window for saving and printing calibration data, as well as a troubleshooting section that addresses common connection issues with the monitor and photometer.
| Operating Systems | Windows XP (32 Bit), Vista (32 Bit) |
|---|---|
| Screen Resolutions | 1024 x 768 and up |
| Display Monitor | JVC GD‑42 X1 |
| Photometer | X‑Rite EyeOne Display 2 |
| Monitor Interface | Serial port or USB‑to‑Serial adapter |
| Photometer Interface | USB port |
Check that the power cord and switch are on, use a crossover serial cable, verify the monitor model and operating system are supported, ensure the USB‑to‑Serial interface appears in the system tray and its driver is up‑to‑date, then power‑cycle the monitor.
Make sure the cable is securely connected to both the photometer and PC, confirm the photometer model is supported, install the latest driver, and verify the device appears in the USB icon area of the system tray.
The software runs on Windows XP (32 Bit) or Vista (32 Bit), requires a screen resolution of 1024 × 768 or higher, a JVC GD‑42 X1 monitor, an X‑Rite EyeOne Display 2 photometer, and a serial or USB‑to‑Serial connection for the monitor plus a USB port for the photometer.
