This drawing is about the wire diagram of FUTEK LCA310.
The FUTEK LCA310 is a miniature load column load cell designed for precise force measurement. The manual lists the drawing number, dimensions, and available capacities for 15 k, 20 k, and 30 k load ranges.
Key specifications include a rated output of 2 mV/V, a safe overload of 150 % of rated output, and a bridge resistance of 350 Ω. The device operates from –60 °F to 200 °F, with temperature compensation from 60 °F to 160 °F, and is constructed from 17‑4PH stainless steel with a #29 AWG spiral‑shielded Teflon cable.
| Rated Output | 2 mV/V nominal |
|---|---|
| Safe Overload | 150 % of rated output |
| Zero Balance | 41 % of rated output |
| Excitation Voltage | Up to 18 V DC or AC |
| Bridge Resistance | 350 Ω nominal |
| Nonlinearity | 0.141 % of rated output |
| Operating Temperature | -60 °F to 200 °F (‑50 °C to 93 °C) |
| Material | 17‑4PH stainless steel |
The rated output is 2 mV/V nominal.
The load cell can be excited with up to 18 V DC or AC.
It operates from –60 °F to 200 °F (‑50 °C to 93 °C).
