LC513FWH1-60Q-A0 is a 5mm round LED lamp produced by Cree, with a 60-degree light angle, white light, and no stopper.
The Cree LC513FWH1-60Q-A0 is a 5 mm round white LED with a water‑transparent lens and a 60° viewing angle. It is intended for flashlights, LCD backlights, and general illumination applications.
The datasheet provides absolute maximum ratings, typical electrical and optical characteristics, mechanical dimensions, RoHS compliance information, and details on standard bins and kit packaging options for ordering. This manual is written in Chinese.
| Forward Voltage (VF) at IF=20 mA | 3.2‑4.0 V |
|---|---|
| Luminous Intensity (IV) at IF=20 mA | 2130‑4000 mcd |
| Chromaticity Coordinate x | 0.31 |
| Power Dissipation | 100 mW |
| Reverse Voltage (VR) | 5 V |
| Operating Temperature | -40 °C to +95 °C |
| Storage Temperature | -40 °C to +100 °C |
The LED has a 60‑degree viewing angle.
It is suitable for flashlights, LCD backlights, and general illumination.
