JH-1711LNA is a single board computer with CPU/CRT/LCD/LVDS/LAN/Audio functions. The product is equipped with an industrial-grade CPU card, a user manual, an IDE cable, COM port adapter cables, a 2*4Pin keyboard/mouse adapter cable, a USB adapter cable with chassis bezel, a 2*8Pin VGA adapter cable, an EVOC CD, and spare jumpers. It is suitable for industrial applications and has safety precautions and features.
The JH-1711LNA is an industrial single‑board computer featuring an Intel Pentium NM ultra‑low‑power CPU, Intel 855GM chipset, and a range of I/O options suitable for embedded applications. It supports up to 1 GB DDR memory, dual LVDS displays, and various peripheral interfaces.
This manual includes a product introduction, safety precautions, installation steps, detailed descriptions of each connector and interface, BIOS configuration, and appendices with address and interrupt tables. It is intended for system integrators and technicians who install and maintain the board. This manual is written in Chinese.
| Dimensions | 216 mm × 146 mm |
|---|---|
| Operating temperature | 0 °C to 60 °C |
| Operating humidity | 5 % to 90 % |
Ground yourself by touching a metal object for about 10 seconds before removing the board from its anti‑static bag.
The board operates from 0 °C up to 60 °C.
