This document details the features and characteristics of the EC9-1711LNA single board computer, including ordering information, environmental and mechanical dimensions, microprocessor, chipset, system memory, network function, IDE function, USB function, display function, audio function, expansion bus, BIOS, Watchdog function, I/O function, power saving characteristics, and other features.
The EVOC EC9-1711LNA is an industrial‑grade motherboard that complies with the Intel Embedded ATX standard and integrates a range of modern PC technologies, including Intel Pentium M processors, multiple video outputs, and extensive I/O.
The manual provides a complete guide to unpacking, safety handling, hardware installation, interface descriptions, BIOS configuration, and watchdog programming, helping users set up the board quickly and safely. This manual is written in Chinese.
| Dimensions | 243.84 mm × 243.84 mm |
|---|---|
| Operating temperature | 0 °C ~ 60 °C |
| Supported CPU | Intel Pentium M (low‑voltage, ULV, etc.) |
| Chipset | Intel 82915GMH GBSM (82801FB) |
| Audio interface | Audio (AC'97) connector |
| Video outputs | VGA, LVDS, DVI, TV (1080i/1920×1080) |
The package contains one EC9-1711LNA industrial motherboard, a user manual, an AMI BIOS settings guide, an IDE cable, a floppy‑disk flat cable, three generic interface cables, three USB cables, an EMGC optical module, and a spare jumper.
