EC3-1811LDNA is a full-featured embedded single board computer developed on the 146mm X102mm size with INTEL 945GM notebook computer chipset. It adopts low power CPU, which can work normally in the range of 0℃~60℃. Its full integration makes it more suitable for various embedded application scenarios.
This manual introduces the EVOC EC3-1811LDNA embedded single‑board computer, describing its hardware features, supported interfaces, and typical applications such as automation control and vehicle multimedia. It also lists the contents of the package and the safety precautions that must be observed when handling the board.
The document covers mechanical dimensions, operating temperature ranges, processor and chipset details, memory capacity, and a full overview of the available connectors (USB, audio, serial, Ethernet, SATA, VGA/LVDS/TV, PS/2, etc.). Installation steps, jumper settings, and programming guides for the watchdog timer are included, along with address mapping tables in the appendix. This manual is written in Chinese.
| Board dimensions | 146 mm × 102 mm |
|---|---|
| Operating temperature | 0 °C to 60 °C (storage -40 °C to 85 °C) |
| Memory | DDRII 533/667 SO‑DIMM, up to 2 GB |
| Processor / Chipset | Intel 945GM chipset with low‑power CPU |
| Ethernet | 10/100/1000 Mbps controller |
| SATA ports | 2 SATA connectors |
| Audio interface | Standard AC97 audio connector |
| Display outputs | VGA, LVDS and TV dual‑display |
Read the manual, keep the board in an anti‑static bag, ground yourself before touching it, disconnect the AC power before any insertion or removal, and wait at least 30 seconds after power‑off before turning it on again.
The board measures 146 mm by 102 mm.
