This document describes the accessories list and installation instructions of the EVOC EC5-1711CLDNA industrial-grade CPU card, including features and characteristics such as CPU, chipset, system memory, and interface functions.
The EVOC EC5-1711CLDNA is an industrial‑grade CPU card that integrates a low‑power Pentium‑M or Celeron‑M processor, Intel 855GM + 82801DB chipset, and a range of I/O interfaces on a compact 203 mm × 146 mm board. It supports a single DDR333 SO‑DIMM module up to 1 GB, dual CRT/LVDS displays, Ethernet, audio, USB 2.0, IDE, CF, and optional Mini‑PCI extensions.
The manual provides detailed safety precautions, step‑by‑step installation instructions, BIOS setup guidance, driver installation notes, and programming details for the built‑in watchdog timer, helping users deploy the card in embedded, networking, or industrial applications. This manual is written in Chinese.
| Dimensions | 8" x 5.75" (203 mm x 146 mm) |
|---|---|
| Operating Temperature | 0 °C to 60 °C |
| CPU | Pentium‑M or Celeron‑M low‑power processor (user selectable) |
| Chipset | Intel 855GM + 82801DB |
| Memory | One 200‑pin DDR333 SO‑DIMM slot, up to 1 GB |
| IDE Interface | 40‑pin ATA100 connector supporting two EIDE devices |
| USB Ports | Four USB 2.0 high‑speed ports |
| Display | Intel 855GME graphics, CRT+LVDS dual display, up to 64 MB shared video memory |
| Network | Intel 100 Mbps LAN |
| Audio | AC'97 audio codec |
| Power Connectors | 4‑pin AT and 20‑pin ATX power connectors |
| Watchdog Timer | Programmable watchdog up to 255 seconds/minutes |
The board supports a single DDR333 SO‑DIMM module up to 1 GB.
The card uses both a 4‑pin AT connector and a 20‑pin ATX connector for power.
