FSC-1714VNA is a full-length card designed with Intel 865GV+ICH5 chipset, supporting LGA 775 architecture 533/800MHz external frequency P4 level processor. It is mainly used for information communication, finance, video surveillance and other high-end applications
This manual covers the EVOC FSC-1714VNA LGA775 motherboard, describing its target applications in information and communication fields and detailing the supported CPU, chipset, memory, and peripheral interfaces. It includes safety precautions, installation steps, BIOS configuration, and interrupt mapping.
Technical sections list hardware dimensions, environmental limits, supported CPUs (533/800 MHz FSB), chipset (Intel 865GV + ICH5), memory capacity (up to 2 GB DDR400/333/266), LAN, USB, VGA, and other I/O connectors, as well as IRQ assignment tables for system integration. This manual is written in Chinese.
| Dimensions | 338 mm × 122 mm |
|---|---|
| Operating Temperature | 0 °C to 60 °C |
| Operating Humidity | 5 % to 90 % |
| CPU Support | 533 MHz / 800 MHz FSB LGA775 |
| Chipset | Intel 865GV + ICH5 |
| Memory | 2 DIMM slots, up to 2 GB DDR400/333/266 (dual‑channel) |
| LAN | 10/100 Mbps Ethernet |
| USB Ports | 6 USB 2.0 ports |
The board operates from 0 °C up to 60 °C.
It provides six USB 2.0 ports.
The board has two DIMM slots supporting up to 2 GB of DDR400/333/266 memory in dual‑channel mode.
It uses the Intel 865GV chipset with an ICH5 southbridge.
