EC5-1713LDNA is an industrial single-board computer with Intel RG82845GV and Intel82562ET chipsets, supports 2GB memory, supports IDE, USB, display, network, audio, PCI, CF card, Watchdog functions, etc
The EVOC EC5-1713LDNA is an industrial‑grade single board computer based on an Intel Pentium 4 processor, supporting up to 1 GB DDR memory, multiple I/O interfaces, and optional TV/LVDS video output. It includes a range of accessories such as power, video, IDE, USB, and serial cables.
The manual covers safety precautions, unpacking, hardware installation, BIOS configuration, driver installation for chipset, VGA, network, and audio, as well as detailed information on digital I/O programming and watchdog timer configuration. This manual is written in Chinese.
| Dimensions | 8" x 5.75" (203 mm x 146 mm) |
|---|---|
| Operating Temperature | 0 °C to 60 °C |
| Maximum Memory | 1 GB DDR DIMM |
| CPU | Intel Pentium 4 Socket 478, FSB 400/533 MHz |
| USB Ports | 4 × USB 2.0 |
| LAN Interface | 10/100 Mbps Ethernet |
| Audio | AC'97 standard audio codec |
| Video Output | TV and dual‑channel LVDS |
