MC68HC908MR32 and MC68HC908MR16 are 8-bit MCUs based on the Freescale Semiconductor's MC68HC08 series. This series of MCUs integrate RAM, ROM, FLASH, analog circuits, timers, watchdogs, etc., and are suitable for low-end consumer electronics, industrial control, medical equipment, etc.
This data sheet provides a comprehensive description of the MC68HC908MR32 and MC68HC908MR16 8‑bit microcontrollers, including block diagrams, pin assignments, and detailed information on each peripheral module such as ADC, clock generator, timers, and serial interfaces. It also contains memory maps, flash block protection details, and electrical characteristics needed for system designers.
The document includes revision history, ordering information, mechanical specifications, and contact details for Freescale technical support worldwide. It is intended for engineers who need to integrate these microcontrollers into their designs.
| Document revision | Rev. 6.1, July 2005 |
|---|
The data sheet is revision 6.1, dated July 2005.
