This document is a user manual for MCF5249 product, which introduces the overview, features, details, functional overview and functional modules of the product.
This manual introduces the MCF5249 ColdFire Integrated Microprocessor, covering its overview, feature set, block diagram, and functional modules such as the DMA controller, EMAC, and internal SRAM. It also describes the processor core, instruction set, and exception handling.
The document details signal descriptions, bus operation, clock and PLL configuration, memory interfaces (SRAM, SDRAM, chip‑selects), timer modules, and system integration features. Revision history, test and debug interfaces, and contact information for Freescale are included.
| Internal SRAM size | 96 KByte |
|---|
The manual is Revision 4.0, dated October 2003.
More information is available at www.freescale.com.
The document was produced by Freescale Semiconductor, Inc.
The MCF5249 includes 96 KByte of internal SRAM.
