This document provides detailed information about the power, DC/AC electrical characteristics, AC timing specifications, and pertinent electrical and physical characteristics of the MPC852T.
The MPC852T is a PowerQUICC™ processor from Freescale Semiconductor featuring a 0.18‑micron core that operates up to 100 MHz with 1.8 V core and 3.3 V I/O voltages. This hardware specifications document describes the device’s power considerations, electrical characteristics, timing, and physical data for use in Ethernet controllers, routers, and related applications.
Key sections include an overview of the architecture, a feature list, maximum tolerated ratings, thermal characteristics, power dissipation data, DC electrical specifications, thermal calculations, and mechanical ordering information. The document also contains reference tables, layout guidelines, and test specifications such as IEEE 1149.1.
| Core voltage | 1.8 V |
|---|---|
| I/O voltage | 3.3 V (5‑V TTL compatible) |
| Maximum standard operating temperature | 95 °C |
| Maximum extended operating temperature | 100 °C |
| Typical power dissipation (1.9 V supply) | Measured at 1.9 V |
The MPC852T core operates at 1.8 V.
The standard maximum temperature is 95 °C, and the extended limit is 100 °C.
Typical power dissipation is measured at a 1.9 V supply.
