This document describes the features and characteristics of M68HC08 Microcontrollers, including the data sheet for MC68HC908SR12 and MC68HC08SR12. It provides the web address for the most up-to-date information and lists the revision history and change summary.
The MC68HC908SR12 (MC68HC08SR12) datasheet from Freescale Semiconductor details the microcontroller's architecture, memory organization, and peripheral modules. It includes sections on general description, CPU, oscillator, clock generator, timer, PWM, analog, ADC, serial interfaces, and more.
Technical information such as operating ranges, electrical characteristics, mechanical specifications, and ordering data are presented, along with revision history (Revision 5.0) and publication date (July 2004). Contact information for Freescale's regional offices is also provided.
