This document is about FS50R12KE3 IGBT-Modules technical information, it includes various characteristics parameters of this product.
The FS50R12KE3 is an IGBT module presented with detailed electrical characteristics such as collector‑emitter voltage, continuous current rating, and switching losses. The sheet also provides thermal parameters, including junction‑to‑case resistance and maximum junction temperature, as well as mechanical data like mounting torque and creepage distance.
Additional sections cover the package outline, typical output and transfer characteristics, and usage conditions with warranty and safety notes for qualified technical personnel.
| Collector‑Emitter Voltage (Vces) | 4200 V |
|---|---|
| Continuous Collector Current (Ic) | 75 A |
| Gate Threshold Voltage | 2.0 V |
The module can withstand up to 4200 V at 25 °C.
The rated continuous collector current is 75 A at 25 °C.
