This datasheet mainly introduces the features and characteristics of SPS01N60C3 Cool MOS™ power transistor
The SPS01N60C3 is an 850 V Cool MOS power transistor featuring ultra‑low gate charge, low on‑state resistance and high avalanche capability. It is RoHS compliant and qualified according to JEDEC® for target applications.
The document lists maximum ratings, thermal characteristics, detailed electrical parameters, gate‑charge data and switching characteristics, enabling designers to evaluate the device for high‑voltage, high‑current applications such as power supplies and motor drives.
| Continuous drain current (Id) at 25 °C | 0.8 A |
|---|---|
| Power dissipation at 25 °C | 11 W |
It can conduct a continuous drain current of 0.8 A at 25 °C.
The transistor can dissipate up to 11 W at a case temperature of 25 °C.
